Nominal Voltage

153.6V (48S)

204.8V (64S)

256V (80S)

307.2V (96S)

Capacity

100Ah

100Ah

100Ah

100Ah

Storage Power

15.36KWh

20.48KWh

25.6KWh

30.72KWh

IR （AC）

≤ 80mΩ

≤ 100mΩ

≤ 120mΩ

≤ 150mΩ

Cycle Life

5000 cycles

Design Life

≥ 10 years

Charging Voltage

168V± 0.5V

228V± 0.5V

284V± 0.5V

340V± 0.5V

Max working Current

100A

Discharge Cut-off Voltage

135V± 0.5V

180V± 0.5V

225V± 0.5V

270V± 0.5V

OperationTemperature Range

Charge：0 ℃~40℃

Storage Temperature

Discharge：-20℃~40℃

OperationTemperature Range

-20℃~40℃

Size(mm)

745*415*590

930*415*590

1120*415*590

1300*415*590

Weight Approximate

195kg

260kg

310kg

360kg

Communication

RS232 -PC,RS485 (B ) -PC

RS485 (A ) -Inverter, Canbus -Inverter

Certification

UN38.3,MSDS,UL1973 (Cell),IEC62619 (Cell)
